Kleppen delen

O ring
Valve Stem Seal. Chevy. 1937-2012. GMC 1942-2012
VALVE STEM SEAL. CHEVY. 1937-2012. GMC 1942-2012
PER/STUK

Design Feature O-Ring
Design Feature 1 O-Ring
Material Code RBB Rubber
Overall Length (Inch) 0.0800
Overall Length (mm) 2.0320
Seal Outer Diameter (mm) 10.6680
Seal…
€ 0,³⁰
0.630 x 0.530
Valve Stem Seal 0.630 x 0.530 in.
VALVE STEM SEAL 0.630 X 0.530 IN.

Cut Tool 11-1439
Guide Outer Diameter 0.530 in
Inside Diameter 0.530 in
Installation Tool 11-1683
Material Viton
Outside Diameter 0.630 in
Seal Length 0.433 IN
Seal Type Positive-Metal Clad
Stem…
€ 1,⁵⁵
0.602 x 0.500 in
Valve Stem Seal 0.602 x 0.500 in.
VALVE STEM SEAL 0.602 X 0.500 IN.

Cut Tool 11-1438
Guide Outer Diameter 0.500 in
Inside Diameter 0.500 in
Installation Tool 11-1684
Material Viton
Outside Diameter 0.602 IN
Seal Length 0.433 IN
Seal Type Positive-Metal Clad
Stem…
€ 1,⁰⁰
11/32
Valve Stem Seal. Premium Silicone 11/32
VALVE STEM SEAL. PREMIUM SILICONE
FITS 11/32 STEM. WITH GUIDE OD UNDER 0.625

Inner Diameter Ribs 1
Inside Diameter 0.700 in
Material Silicone
Outside Diameter 0.750 in
Seal Length 0.638 IN
Seal Type Umbrella
Valve Stem Size 11/32…
€ 1,¹⁵
235 CU
Push Rob 3.8l. 235Ci Sold each. Lengte = 286 mm
Push Rob 3.8l. 235Ci Sold each.
Lengte = 286 mm

Bottom Tip Diameter (in) 0.470
Bottom Tip Diameter (mm) 11.938
Bottom Tip Type Rounded End
Diameter (IN) 0.312
Diameter (MM) 7.925
Overall lenghte ( in ) 11.29
Length (MM) Top to…
€ 18,⁹⁵
Intake
Intake Valve. Length = 6.391 in, / Head Dia. = 1.875 In
Intake Valve. Length = 6.391 in, / Head Dia. = 1.875 In 235 Chevrolet Engine

Length 6.391 / 162.3 mm
Lock Groove Qty 2
Stem Diameter 0.3415 / 8.67 mm
Valve Head Diameter 1.875 / 47.63 mm
€ 19,⁹⁵
Exhaust
Exhaust Valve . Lenghte 4.921 In, / Head Dia. 1.50 In
Exhaust Valve . Lenghte 4.921 In, / Head Dia. 1.50 In 235 Chevrolet engine

Length 4.921 in / 124.99 mm
Lock Groove Quantity 2
Material Tapered stem
Stem Diameter 0.3413 in / 8.67 mm
Stem Diameter 11/32 in / 8.731 mm
Valve Head…
€ 17,⁹⁵
Valve Guide
Valve Guide

Inner Diameter (IN) 0.3435
Length (IN) 2.438
Material Iron
Outer Diameter (IN) 0.565
Type 1-Plain I.D.
€ 5,⁹⁵
